SV-H6D Advanced Thermal Imaging Camera

SV-H6D is equipped with 640 × 480 thermal resolution detector. Inspectors can survey high-voltage, hazardous targets safely and quickly diagnose electrical and mechanical failures. Interchangeable lenses offer complete coverage of near and distant targets, with the laser distance meter ensuring the crisp focus needed for accurate temperature measurement.

Quantity:
  • SV-H3D/SV-H6D
  • SUANGSI

Introduction:


SV-H6D series handheld thermal imaging camera is equipped with a 640x480 high-sensitivity infrared detector.

With the advantages of accurate temperature measurement, clear imaging, simple and easy to use, lightweight and portable, it can support the rapid judgment of the environment. High and low temperature conditions, one-click capture and video functions, which are convenient for field operators to record and troubleshoot faults. This instrument can be widely used in power stations, industrial inspections, petrochemicals, electronic design, building energy conservation and etc.


Model:

SV-H3D/SV-H6D


Features:

l  High-sensitivity uncooled infrared detector

l  Compact, lightweight and portable, rugged and ergonomic

l  Clear software interface, easy to operate quickly

l  Long-range non-contact accurate temperature measurement up to 650°C (can be extended to 2000°C)

l  Visible and thermal display modes 5.0"TFT touch screen

l  High and low temperature alarm

l  Capture, video recording, file saving

l  Multiple Data Transmission Interfaces & Extended Applications: SD card and Micro HDMI interface


Imaging performance

Detector Type

Uncooled Detector

Detector Resolution

640 × 480

Spectral Range

8~14μm

Detector Pitch

17μm

Lens

Standard 24° (optional 48°、12°、7°)

IFOV

0.68mrad(24°),1.30mrad(48°),0.34mrad(12°), 0.17mrad(6°)

FOV

24°×18°,48°×36°,12°×9°,6°×5°

NETD

< 50mk(@30°C,F#=1.0)

Focus

Manual/Automatic/Electric

Image Frequency

30HZ

Digital Zoom

×1、×2、×4、×8


Image Display

Display Technology

IPS

Display Screen

5 inch Sunlight Readable Display

Touchscreen

Capacitive touch screen

Image Mode

Visible light, thermal imaging, picture-in-picture, image fusion

Color Palettes

10 false colors such as Iron red/grayscale/anti-iron red/anti-grayscale etc.

Isothermal Line

Yes

Temperature Difference

Each temperature measuring frame automatically temperature difference calculate


Storage and Analysis

Storage Card

32 G high-speed SD card (can store more than 4000 infrared pictures)

Video Recording

H.264 format video recording

Infrared image format

jpg (including full temperature data)/ png (including full temperature data)

Visiable image format

jpg/png

Image Library

Yes

Text

Predefined list or touchscreen keyboard

Voice

Recording added to still images


Temperature measurement performance

Accuracy

±2℃ or ±2% of reading

Range

-20°C~150°C、0°C ~410°C( can be extended to 2000℃)

Intelligent Range

Yes

Emissivity Correction

0.01-1, custom input and material table selection

Temperature Correction

Atmospheric transmittance, optical correction, ambient temperature and humidity, automatic target distance correction

High temperature alarm

High temperature abnormal alarm

Temperature measurement model

Global high and low temperature, average temperature tracking. Point, line, and frame temperature measurement, 10 points, 5 regions, and 5 lines measure simultaneously.

Alarm Mode

Automatic sound and light alarm for the set temperature value / above / below


Connections and Communications

4G

Real-time remote images streaming to mobile phones/computers via 4G

GPS

Automatic image tagging

Bluetooth

Voice annotation listen via Bluetooth

WIFI

Yes

HDMI

Real-time video streaming via Micro HDMI


Environmental Parameter

Encapsulation

IP45

Operating Temperature

-20°C~+50°C

Operating Humidity

0-90%

Storage Temperature

-40°C~60°C


Power

Charging temperature

0℃~45℃

Charge Mode

Two-places Charger or 12V Car Charger

Battery Type

Detachable Rechargeable Li-ion battery

Battery life

>2.5h at 25°C ambient temperature and typical use

Power

Support Sleep Mode

External Power Management

USB 2.0 A to USB Type-C with Power Supply


Product Specification

Power Consumption

6W

Size (L x W x H)

260x 135 x136mm

Weight

1.17Kg (incl battery)

Housing Material

TPE coated PCABS, Magnesium Alloy
